Rated load

20,30,50,75,100,150,200,250,300,500,700,850,1000kg; 1.2,1.5, 2,2.5,3.5,7.5,10t

 Rated output (mV/V)

2.0-+0.015mV/V 3.0-+0.015mV/V 0~5V 0~10V4~20mA

 Composite error

-+0.05%F.S

 Creep (30minutes)

-+0.02%F.S

 Zero balance

-+1%F.S

 Zero temperature influence

-+0.05%F.S/10

 Output temperature influence

-+0.1%F.S/10

 Input impedance

380-+5

 Output impedance

350-+3

 Insulation resistance

>5000M

 Working temperature range

-30~+70

 Safety overload

120%F.S

 Limiting overload

200%F.S

Recommended excitation voltage

10~24VDC

 Max excitation voltage

30VDC

 Protection class

IP66,IP67

 Materials

 Alloy steel or Aluminum

 Cable

Length:3m Diameter: 5mm
