Characteristics
High temperature load cell, planar load bearing bridge, reasonable structure. Simple and reliable load bearing, easy to use, simple to install. Widely used in consecutive-casting bale scale, middle bag scale steel ladle scale, traveling crance scale and other weighing systems in steel industry.

 Rated output (mV/V)

1.50-+0.010

 Nonlinearity

-+0.10%FS

 Hysteresis

-+0.05%FS

 Repeatability

-+0.02%FS

 Creep (30minutes)

-+0.02%FS

 Zero baiance

-+1.00%FS

 Temperature effect on zero

-+0.02%FS/10

 Temperature effect on output

-+0.02%FS/10

 Input resistance

770-+15

 Output resistance

700-+3

 Insulation resistance

>5000M

 Excitation voltage

10V(DC/AC)

 Compensated temperature range

-10~+50

 Operating temperature range

-20~+60

 Safe overload

120%FS

 Cable

6X10m

 Materials

 Alloy steel

 Cable color code

 Input: Red(+) Black(-)

 Output: Green(+) White(-)
