Characteristics
A protection device of crane machinery on lateral meter bridge, gate, and shore tackle, etc. Specially used in electric block single point crane. The most obvious advantage is the separation of test elements and lateral meter components, to reduce maintain cost and easier use.

 Rated output (mV/V)

2.00-+0.10

 Nonlinearity

-+0.10%FS

 Hysteresis

-+0.10%FS

 Repeatability

-+0.05%FS

 Creep (30minutes)

-+0.02%FS

 Zero baiance

-+1.00%FS

 Temperature effect on zero

-+0.02%FS/10

 Temperature effect on output

-+0.02%FS/10

 Input resistance

385-+10

 Output resistance

350-+3

 Insulation resistance

>5000M

 Excitation voltage

10V(DC/AC)

 Compensated temperature range

-10~+50

 Operating temperature range

-20~+60

 Safe overload

200%FS

 Cable

5.4X0.5m

 Materials

 Alloy steel, stainless steel

 Cable color code

 Input: Red(+) Black(-)

 Output: Green(+) White(-)
