Characteristics
Unique technics, good seal structure. High security and stability. Suitable for travelling crane and lifting structure. Customized size is available.

 Rated output (mV/V)

1.00-+10

 Nonlinearity

-+0.10%S

 Hysteresis

-+0.10%S

 Repeatability

-+0.03%S

 Creep (30minutes)

-+0.05%S

 Zero baiance

-+1.00%S

 Temperature effect on zero

-+0.05 -+0.10

 Temperature effect on output

-+0.05 -+0.10

 Input resistance

385-+10

 Output resistance

350-+3

 Insulation resistance

>5000M

 Excitation voltage

10V(DC/AC)

 Compensated temperature range

-10~+50

 Operating temperature range

-20~+60

 Safe overload

120%FS

 Cable

5.4X3(5)m

 Materials

 Alloy steel, stainless steel

 Cable color code

 Input: Red(+) Black(-)

 Output: Green(+) White(-)
