Features
- Virous of actuators, action position is adjustable(such as EM1701)
- High switch on and off capacity(15A)
- High accuracy
- Wide range of operation speed
- Each type of EM series has solder terminal, screw terminal and tab terminal are selective
- Add A for solder terminal, add C for tab terminal, blank for screw terminal
Characteristics
| Operation speed |
0.01mm-1m/sec |
|
|
| Operating frequency |
Mechanical: 240 operations/min. Electical: 20 operations/min. |
Contact resistance |
15m max. |
| IInsulation resistance |
100m min. (at 500VDC) |
| Dielectric strength |
1000VAC, 50/60 Hz for 1 minute between terminals of the same polarity |
1500VAC, 50/60 HZ for 1 minute between current-carrying and non-current-
carrying metal parts |
| 1500VAC, 50/60 HZ for 1 minute between each terminal and ground |
| Vibration |
10-55Hz,1.5mm double amplitude |
| Shock |
Mechanical durable: 1, 000m/Sec2(about 100G'S)
Malfunction: 300m/Sec2(about 30G'S)
|
Ambient temperature |
General purpose type: -25 to +80 Sealed type: -15 to +80 |
| Humidity |
General purpose type: 85% RH max., Sealed type: 95% RH max. |
Life |
Mechanical: 20,000,000 operations/min.
Electrical: 500,000 operations/min. |
| Weight |
About 22 to 58g |
|
Terminal Type  |
Contact Form  |
Operating Characteristics
|
Models |
EM1300 |
EM1301 |
EM1303 |
EM1305 |
EM1306 |
EM1307 |
EM1308 |
EM1309 |
EM1701 |
EM1702 |
EM1703 |
EM1704 |
EM1705 |
EM1743 |
|
OF(Max.) |
350g |
300g |
300g |
350g |
350g |
350g |
350g |
350g |
70g |
100g |
160g |
160g |
10g |
160g |
|
RF(Min.) |
114g |
50g |
50g |
114g |
114g |
114g |
114g |
114g |
14g |
28g |
22g |
42g |
3g |
42g |
|
PT(Max.) |
0.4mm |
4mm |
4mm |
0.4mm |
0.4mm |
0.4mm |
0.4mm |
0.4mm |
10mm |
5mm |
7.1mm |
2.7mm |
20mm |
2.7mm |
|
OT(Min.) |
0.13mm |
1.6mm |
1.6mm |
1.6mm |
1.6mm |
5.5mm |
3.58mm |
3.58mm |
5.6mm |
2mm |
4mm |
2.4mm |
5.6mm |
2.4mm |
|
MD(Max.) |
0.05mm |
1.3mm |
1.3mm |
0.05mm |
0.05mm |
0.05mm |
0.05mm |
0.05mm |
1.27mm |
1mm |
1.02mm |
0.5mm |
3mm |
0.5mm |
|
FP(Max.) |
|
20.6mm |
31.8mm |
|
|
|
|
|
28.2mm |
24.8mm |
36.5mm |
32.5mm |
|
43.6mm |
|
OP(mm) |
15.9+-0.4 |
17.4+-0.8 |
28.6+-0.8 |
28.2+-0.5 |
21.5+-0.5 |
21.8+-0.8 |
33.4+-1.2 |
33.4+-1.2 |
19+-0.8 |
19 0.4 |
30.2 0.8 |
30.2 0.4 |
19 0.4 |
43.1 0.8 |
|
Operating Characteristics  |
|
