Pushbutton switch EBFM-30

Products: Limit switch View: 2419Frequency

Ratings

Rated
voltage

Noninductive Load (A)

nductive Load (A)

Inrush Current

Resistance Load Lamp Load

Inductive Load

Motor Load

NC NO NC NO
NC

NO

NC

NO

NC

NO

125VAC
250VAC
500VAC
15
15
3
3
2.5
1.5 1.5
1.25
0.75
15
15
2.5

5
3
1.5

2.5
1.5
0.75

max.

max.

8VDC
14VDC
30VDC
125VDC
250VDC
15
15
6(2)
0.4
0.2 3
3
3
0.4
0.2 1.5
1.5
1.5
0.4
0.2
15
10
5
0.05
0.03

5
5
5
0.05
0.03

2.5
2.5
2.5
0.05
0.03

Characteristics

Operation speed	0.01mm-1m/sec
Operating frequency	Mechanical: 240 operations/min. Electical: 20 operations/min.
Contact resistance	15m��bleow(initial )
IInsulation resistance	100m��above (at 500VDC)
Life	Mechanical: 20,000,000 times above. Electrical: 500,000 times above.

Notes: 1. Each type has solder terminal, screw terminal and tab terminal, which are all selective.
2. Converse operation of actuator is always kept because of the compressiong of spring.It will be free and do switch on and off action under lever action.Because when the polestopper is kept by actuators (free state) so it can bear vibration and hitting.

Terminal Type

Contact Form

Model Designations

15A 250VAC CM Micro Switch

Items	Code	Details
Model	EBFM EBLM EBMM	Even button Convex head Big head
Fixed hole distance	25 30	��25m/m ��30m/m
Connection terminal	B A C	Screw terminal Weld terminal Tab terminal
Color of pushbutton switch	R G Y B W	Red Green Yellow Black White

Contact type 10=1NO, 01=1NC, 11=1NO+1NC, 22=2NO+2NC

Appearance and Dimension

Model
	Size(mm)
	D	d	L1	L2
EBF-25-30	21(24.5)	30(34)	16(18.5)	40/48
EBF-25-30	40	30	31	40/48
EBM-25-30	40	30	35	42/50
ESS-25-30	21	30	33	43/51
EIBN-25-30	19	30	33	46/55
EBK-25-30	40	30	35	42/50
